VIN Code Laser Marking Subsystem

Newlaz VIN code laser marking subsystem can replace traditional mechanical marking systems with high efficiency and good passability. It can be coded at multiple locations on the vehicle body and can be used by multiple vehicle models.

Application

VIN Code Marking

Document

Newlaz VIN code laser marking subsystem uses a laser and galvanometer system to engrave VIN code characters on the vehicle body. The width and depth of the characters meet the requirements of the OEM and regulations.

Newlaz VIN code laser marking subsystem can replace traditional mechanical marking systems with high efficiency and good passability. It can be coded at multiple locations on the vehicle body and can be used by multiple vehicle models.

VIN Code Laser Marking Subsystem
Common marking locations

System Configuration

VIN Code Laser Marking Subsystem

Functions

  • Visual detection: status feedback
  • Adaptive function: ensures reliable contact between the dock and the vehicle body surface;
  • Anti-splash: reduce lens detection, improve marking quality
  • Lens detection: ensure equipment stability
  • Customized software: development with manual VIN code input function

Advantages

  • Non-contact marking, strong adaptability
  • Applicable to multiple car models with flexible location
  • Marking can be achieved on different thicknesses and materials
  • Fast marking speed, only 20s
